3PH Direct (100A) MID - RISH ED43X1
Rish ED43X1 supports a three-phase direct connection max. 100A, saving money & reducing the hassle of connecting additional CTs. With remote monitoring & setting, there's a SO output along with a MODBUS port available. Suitable for measuring energy usage in utility, industrial, & EV charging system applications.
Download & Share
RISH ED43X1 is a modern Three Phase Direct Connected Energy Meter designed for intended use in residential, commercial and light industrial Electrical Energy Metering. The meter is engineered using advanced microcontroller technology and is suitable for electrical parameter measurement and monitoring in 3 Phase 4 Wire, 3 Phase 3 Wire and 1 Phase 2 Wire Networks. It supports a maximum 100 A current measurement on direct connection. It supports Tariff Counters selectable via Digital Input. It displays parameters on a bright intuitive LCD and also has Pulse Outputs and Impulse LED for energy monitoring. It has industry standard MODBUS RTU/MBUS for remote monitoring. Meter housing is standard Din Rail Mount that allows ease of installation.
Product Features:-
- MID certified (2014/32/EU – MI-003)
- Tamper-proof metrological sealing
- Module B & D approved
- Legally compliant energy billing
- Three Phase Direct Current Operated Energy Meter - self powered
- TRMS measurement
- Size 4U (width-72mm)
- LCD Display-1 line 8 digit seven segment LCD display for Energy
- Accuracy Class B as per EN 50470-3 (Class 1 as per IEC 62053-21)
- Energy measurement as per IEC 62053-21,23
- Bi - Directional Import & Export energy measurement
- Measure Demand parameters active,reactive power (Import/Export), apparent power & current
- RS485/MBus communication (Optional)
- Multi tariff Counters for energy accumulation which are selectable via two Digital inputs
- 2 SO Pulse output for Import/Export energy measurement
- Terminal Sealing arrangement
- Laser Marking (for product information)
