Rish ED21X1
RISH ED21X1 measures important electrical parameters in 1Ph 2 Wire Networks.The meter is available in 100A Max.current measurement range on direct connection.The instrument has 2 SO outputs and 1DI for tariff counter.It displays parameters on bright LCD, Impulse LED for energy monitoring.
Download & shares
RISH ED21X1 is a modern Single Phase Direct Connected Energy Meter designed for intended use in residential, commercial and light industrial Electrical Energy Metering. The meter is engineered using advanced microcontroller technology and is suitable for electrical parameter measurement and monitoring in 1 Phase 2 Wire Networks. The meter is available in 63 and 100 A maximum current measurement range on direct connection. It supports Tariff Counters selectable via Digital Input or MODBUS Communication. It displays parameters on bright intuitive LCD and also has Pulse Outputs and Impulse LED for energy monitoring. It has inbuilt industry standard MODBUS RTU for remote monitoring. Meter housing is standard Din Rail Mount that allows ease of installation.
Features
DIN Mounted Energy meter - Energy measurement as per IEC 62053-21,23 , IEC 61557-12, EN 50470-3 Class B
Direct Connected Energy meter with self powered
On display indication - Digital Input / Output
Pulse outputs configurable for Import/Export Energy measurement
Digital Inputs – Tariff Energy Accumulation·
Optional SO Pulse output for energy application along with 1 Digital Input
Accuracy Class B as per EN 50470-3 (Class 1 as per IEC 62053-21,23)
Max demand power
Bi - Directional measurement IMP & EXP
Terminal Sealing Protection
Laser Marking (for product information)
Optional RS485 communication
TRMS measurement
